Description
The actuator set consists of the following elements:
- Lamp holder with 3 colored lights (max. 12 V)
- DC motor (2-bit) (max. 12 V)
- Buzzer (max. 12 V)
- Push button
- 3 black and 3 red 4mm wires
- A propeller and a pulley for mounting on the motor shaft.
All elements are equipped with 4mm sockets.
The Actuator Set can be used to build and program simple measurement and control systems:
- A traffic light: using the pushbutton, the traffic light can respond to input from pedestrians. An additional light sensor allows the traffic light to flash in the dark.
- A temperature control: if the temperature gets too high, the heatsink (with an additional temperature sensor) switches on. Shop window lighting: when it gets dark, the light should turn on (with an additional light sensor).
- Alarm system
The “Control and Regulate” Coach project offers a programming environment for this purpose.
For BT inputs the CMA adapter (art. Nr 0519) should be used.
Technical specifications of the Actuator set are described in the product manual, see downloads.
