Angle position sensor

Angle position sensor

Item nr. 013i Category
The sensor is suitable for detecting angles, and (small) displacements. The range of the sensor is 270° of turn or a displacement of about 140 mm.

15 in stock

Add to wishlist
View wishlist

Description

The Angle position sensor contains a potentiometer with a pulley to attach a string to. By a displacement of a string, the potentiometer is rotated and the output voltage is adapted.

The Angle position sensor can be used in physics to:

  • Studying the swing of a pendulum
  • Measurements of small displacement
  • Measurement of positions of the light sensor in interference and diffraction patterns

The Angle position sensor can be directly connected to analog BT inputs of the CMA interfaces.

Technical specifications of the sensor are described in the product manual, see downloads.

Additional information

Weight 0,13 kg
Dimensions 20 × 10 × 4 cm

Product manual

Download
