Voltage sensor -12..12 V

Item nr. BT31i Category
This differential Voltage sensor is designed for exploring the basic principles of electricity. With a wide input voltage range of -12 to 12 V this sensor can be used to measure voltages in AC and DC circuits.

120 in stock

Add to wishlist
View wishlist

Description

The sensor has differential inputs, which means that measurements can be done directly across circuit elements without the constraints of common grounding.
It has two banana (4-mm) plugs for easy connection.

Technical specifications:

  • Measurement range: -12 .. +12 V (voltage between input terminals)
  • Max input voltage: ± 50 V
  • Input impedance to ground: 1 MW
  • Required: One sensor cable (BTsc_1 or BTsc_1Short)
  • Warrantee: 3 years

All technical specifications of the sensor are described in the product manual, see downloads.

The (differential) voltage sensor can be used in a variety of physics experiments, such as:

  • Measurements in series and parallel circuits
  • Voltage / Current relationships
  • Electrical component characteristics e.g. a light bulb, a diode, a light dependent resistor
  • Charging and discharging capacitors
  • Ohm’s law
  • Measurements of internal resonance and EMF

Additional information

Weight 0,135 kg
Dimensions 20 × 10 × 4 cm
